- 1. Grip set: 19005-3000010
- 2. Rear brake assembly Tektro HD-E3520: 19008-2200070
- 3. Shifter: 19300-1000189
- 4. Handlebar: 30522-3170005
- 5. BC280 display: 19004-2100092
- 6. Stem: 19005-5000060
- 8. Headlight: 19004-6100052
- 9. Throttle: 19004-5200022
- 10. Front brake assembly Tektro HD-E3520: 19008-5000060
- 12. Top cap assembly: 19005-6000010
- 17. Saddle: 19005-8000031
- 18. Suspension seat post: S/T Sz. L & S/O Sz. R & L: 19005-7100020 S/T Sz. R: 19005-7100060
- 19. Seat post clamp: 19005-7200030
- 21. 8 speed chain (118 link): 19006-3400020
- 22. Chain stay guard: 19012-2400010
- 24. Cable retainer tab: 19004-9000122
- 27. Left taillight: 19004-6200062
- 29. E-wheel lock assembly: 19004-3200042
- 31. Derailleur hanger: 19007-6000030
- 32. Right taillight: 19004-6200072
- 33. Derailleur: 19300-1000188
- 35. Hub lock plate: 19004-3200032
- 36. Rear 180mm brake rotor: 19003-8000082
- 37. Rear wheel assembly: 19003-0200140
- 38. Rear spokes (198mm): 30321-0198003-kit
- 40. Rear 26x4.0 tire: 19300-1000257
- 41. Rear wheel reflector: 30350-0000009
- 43. 8 speed cassette: 19300-1000193
- 45. Rear rack assembly: 19010-2000180
-
47. Rear fender: ST R: 19009-1200080
ST L: 19009-1200100
SO R: 19009-1200090 SO L:
19009-1200110 - 48. Rear fender stay: 30914-1001011
- 49. Headset spacers: 19005-6100060
- 50. Headset assembly: 19005-6100060
- 51. ACU: 19004-1300032
- 53. Fork: 19005-1100060
- 54. Controller: 19004-1200040
- 58. Pedal set: 19006-2000020
- 59. Crankset: 19006-1000030
- 60. Torque sensor: 19004-5400020
- 63. Kickstand: 19010-6200040
- 66. Battery terminal: 19004-4400102
- 68. Battery: 19004-4100062
- 69. Battery cover: 19004-9000112
- 72. Battery e-lock assembly: 19004-0100072
- 75. Cable cover plate (battery compartment): 19004-9000102
- 77. Front 26x4.0 tire: 19300-1000257
- 80. Front drive side spokes (249mm): 30322-0249002-kit
- 81. Front non-drive side spokes (247mm): 30322-0247002-kit
- 82. Front 180mm brake rotor: 19003-8000082
- 83. Front wheel assembly: 19100-0700053
- 84. Front wheel reflector: 30350-0000008
- 85. Front fender: 19009-1100041
- 89. Front fender stays: 30913-1001011
- 97. Front and rear lights wire harness: 19004-8000162
- 98. Motor wire harness: 19004-8000092
- 100. Throttle & brake sensor wire harness: 19004-8000222
- 101. Main display wire harness: 19004-8000242
- 102. Lock harness extension cable: 19004-8000202
- Front and rear fender set:
S/O size: R: 19009-1000110
S/O size: L: 19009-1000130
S/T size: R: 19009-1000100
S/T size: L: 19009-1000120
